Gaoxin Industrial Park, Guangming New Zone, Shenzhen w prowincji Guangdong, Chiny | Angelwang66@126.com |
Place of Origin: | China |
Nazwa handlowa: | STARWELL |
Orzecznictwo: | UL,CE,ROHS, FCC,GS,SAA,C-TICK |
Model Number: | AT14C500-46 |
Minimum Order Quantity: | 1 |
---|---|
Cena: | negotiation |
Packaging Details: | Carton box |
Delivery Time: | 10-15 days |
Payment Terms: | Ex works |
Supply Ability: | 1, 000, 000PCS/week |
High Light: | Led Panel Driver,External led driver |
---|
12V To 24V 14W Led Power Supply / 500Ma Constant Current Led Driver ROHS SAA
Short Features :
> Model : AT14C500-46
> input voltage range : 100~240VAC
> output : 12~24V 500mA 14W
> Output type : constant current
> PF : >0.95
> Ripple and Noise : 100mV maximum
> Effiency : 85% minimum
> Net Weight : 200g
> Dimension : 88(H)*38(W)*22(H)mm
> Safety protection : over load, over voltage, short ciruict, open load protection.
> Certificate : UL,CE,FCC,GS, SAA,C-TICK,CB,KC certificates.
> Application : Led down light , led panel , led strip light , etc......
Specifications
Input Rated Voltage : |
100Vac~240Vac |
Input Frequency Range: |
47Hz~63Hz |
Input Inrush Current : |
1.8A max |
Efficiency : |
85%(MIN)at Rated Voltage |
Output: |
12~24V 500mA |
Output power : |
14W |
Ripple and Noise : |
<150Mv at full road with 20MHz bandwidth |
Turn On Delay Time: |
<3S (AC:110V and full load) |
Safety protection : |
over voltage and current protection. |
Leakage Current: |
<5mA |
Output typer: |
Constant current |
Operating Temperature: |
0°C----+60°C |
Storage Temperature: |
-20°C----+85°C |
Certificate: |
CE GS TUV UL/CUL FCC ROHS,SAA,PSE,C-TICK |
Safety Standard : |
EN 55015:2006; EN 61547:1995+A1:2000 ;EN 61000-3-2:2006; EN61000-3-2:1995+A2:2005; EN 61347-1:2008 EN 61347-2-13:2006 |
Application: |
For led light, led strip, led down light etc…. |
MODEL LIST:
CONSTANT CURRENT LED DRIVER |
|||||||
Model |
Input Voltage |
Output Power |
Output Voltage |
Output Current |
Power Factor |
appication |
Dimension |
SW-AT1C350-45 |
100-240V |
1W |
2.5V-5V |
350mA±5% |
0.95 |
1*1W |
68*33*22 |
SW-AT3C700-45 |
3W |
2.5V-5V |
700mA±5% |
1*3W |
|||
SW-AT3C350-45 |
100-240V |
3W |
5V-11V |
350mA±5% |
0.95 |
2-3*1W |
68*33*22 |
SW-AT6C500-45 |
6W |
5V-11V |
500mA±5% |
2-3*2W |
|||
SW-AT9C700-45 |
100-240V |
9W |
5V-11V |
700mA±5% |
0.95 |
2*3*3W |
68*33*22 |
SW-AT7C350-45 |
7W |
11-25V |
350mA±5% |
4-7*1W |
|||
SW-AT9C350-46 |
100-240V |
9W |
24V-33V |
350mA±5% |
0.95 |
8-10*1W |
88*38*22 |
SW-AT9C700-46 |
12Vmax |
700mA±5% |
4*3W |
||||
SW-AT12C350-46 |
100-240V |
12W |
24-44V |
350mA±5% |
0.95 |
8-13*1W |
88*38*22 |
SW-AT12C700-46 |
8V-14V |
700mA±5% |
3*4*3W |
||||
SW-AT15C350-47 |
100-240V |
15W |
36-54V |
350mA±5% |
0.95 |
10-16*1W |
110*42*24 |
SW-AT15C700-47 |
12-18V |
700mA±5% |
4-5*3W |
||||
SW-AT18C350-47 |
100-240V |
18W |
36V-64V |
350mA±5% |
0.95 |
12-18*1W |
110*42*24 |
SW-AT18C700-47 |
15V-22V |
700mA±5% |
5-6*3W |
||||
SW-AT24C350-48 |
100-240V |
24W |
63-86V |
350mA±5% |
0.95 |
18-26*1W |
132*45*24 |
SW-AT24C350-48 |
21-30V |
700mA±5% |
7-9*3W |
||||
SW-AT27C350-48 |
100-240V |
27W |
72-96V |
350mA±5% |
0.95 |
22-32*1W |
132*45*24 |
SW-AT27C700-48 |
24-33V |
700mA±5% |
8-10*3w |
||||
SW-AT30C350-48 |
100-240V |
30W |
105Vmax |
350mA±5% |
0.95 |
25-30*1W |
132*45*24 |
SW-AT30C700-48 |
36V max |
700mA±5% |
10*3W |
||||
SW-AT50C1500-49 |
100-240V |
50W |
36Vmax |
1500mA±5% |
0.95 |
high power led |
157*57*36 |
SW-AT50C700-49 |
70Vmax |
700mA±5% |
|||||
SW-AT50C1000-49 |
100-240V |
50W |
50Vmax |
1000mA±5% |
0.95 |
high power led |
157*57*36 |
SW-AT60C1800-49 |
60W |
36Vmax |
1800mA±5% |
Applications :
For led light, led strip, led down light etc….
INSTRUCTION :
- For indoor application
- The mains plug is used as the disconnect device, the disconnect device shall be readily operable.
- The socket-outlet shall be installed near the equipment and shall be easily accessible.
- No naked flame source, such as lighted candles, should be placed on the apparatus.
- Maximum operating ambient for the equipment is 40℃.
- The apparatus should not be used in a confined space such as a bookcase.
- This appliance is not intended for use by persons (including children) with reduced physical,
sensory, or mental capacities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their Safety.
- Children should be supervised to ensure that they do not play with the appliance.
Package information :
1. carton box dimension: 480*450*180mm
2. QTY: 50 pcs/carton
3. G.W: 11.5 KG
