LED Tunnel light Waterproof Led Power Supply / constant current led driver

LED Tunnel light Waterproof Led Power Supply / constant current led driver

    • LED Tunnel light Waterproof Led Power Supply / constant current led driver
    • LED Tunnel light Waterproof Led Power Supply / constant current led driver
    • LED Tunnel light Waterproof Led Power Supply / constant current led driver
  • LED Tunnel light Waterproof Led Power Supply / constant current led driver

    Szczegóły Produktu:

    Place of Origin: China
    Nazwa handlowa: G-ORIENT
    Orzecznictwo: CE, ROHS, SAA, FCC, TUV, etc.,
    Model Number: GDW50-AE

    Zapłata:

    Minimum Order Quantity: 10pcs
    Cena: Negotiable
    Packaging Details: 40PCS/CTN, GW:8.5KGS, Carton Size: 31 x 19 x 17.5CM
    Delivery Time: 7-15 work days
    Payment Terms: L/C, T/T, Western Union, Paypal
    Supply Ability: 60,000set/mon
    Skontaktuj się teraz
    Szczegółowy opis produktu
    Input Voltage: 85-277VAC Output Voltage: 12-36VDC
    Power Rated: 50W Efficiency: 0.88 Max
    Protecion Grade: IP66 PFC: >0.95
    Orzecznictwo: CE,ROHS,FCC,SAA,TUV, etc., Case: Aluminum

    LED Tunnel light Waterproof Led Power Supply / constant current led driver

    Features:

    * Input Voltage: AC85-277V

    * Output: Costant Current
    * High efficiency, High reliability, Low cost
    * Protections: Short circuit/Over load/Over voltage/High temperature
    * Waterproof grade: IP66, water proof and dust proof
    * Working Frequency: 65 KHz
    * Suitable for LED lighting, Like LED Downlight, Flood Light, LED strip light, LED Wall Wash Light, etc.,
    * Aluminum Case



    Competitive Advantages:

    * PFC>0.95

    * High efficiency up to 88%

    * 3 years warranty

    * CE / ROHS / FCC/SAA approval

    * Customized is available

    * IP66


    Specification:

    Model

    GDW50-AE-12

    GDW50-AE-24

    GDW50-AE-36

    ------







    output

    DC voltage

    12V

    24V

    36V

    ------

    Voltage tolerance

    ±1%

    ±1%

    ±1%

    ------

    Rated current

    4.2A

    2.1A

    1.4A

    ------

    Current range

    0~4.2A

    0~2.1A

    0~1.4A

    ------

    Rated power

    50.4W

    50.4W

    50.4W

    ------

    Ripple&noise

    100mvp-p

    150mvp-p

    180mvp-p

    ------





    input

    Voltage range

    AC85-277V,235~373VDC

    Frequency

    47~63HZ

    AC current

    0.5A/230VAC

    Efficiency

    84%

    85%

    88%

    ------

    Inrush current

    Cold start current 35A/230VAC

    Leakage current

    <1mA/240VAC

    protection

    Over load

    Rated output power 115%~150%start over load protection

    Protection type: hiccup mode,auto-recovery after fault condition is removed

    Over voltage

    15.6~17.8V

    30.6~33.2V

    42.6~44.2V

      -------

    Protection type: hiccup mode,auto-recovery after fault condition is removed

    Over temperature

    Shell temp85°C,start over temperature protection

    Protection mode: cutoff output,auto-recovery after temperature become normal

    environment

    Working temp,humidity

    -10°C~+60°C,20%~90%RH

    Storage temp.humidity

    -20°C~+85°C,10%~95%RH non condensing

    Withstand vibration

    10~500HZ,2G 10min/1cycle,period for 60minutes,each axes

    safety

    Withstand voltage

    I/P-O/P: 1.5KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC

    Isolated resistance

    I/P-O/P,I/P-FG,O/P-FG: 100M ohms/500VDC

    Fits

    tandard

    Safety standard

    Fit UL1012,IP67 protect level

    EMC standard

    Fit EN55022,CLASSA

    Others

    Dimension

    139*42*29mm (L*W*H)

    Weight/packing

    0.21kg/30pcs/10..5kg





    Application:
    * Widely used in LED Lighting, LED Street light, LED flood Light, LED Tunnel light, Wall Wahs LED light, etc.,
    * IP66 waterproof and dustproof, can operate in hard conditions and enviroment


    LED Tunnel light Waterproof Led Power Supply / constant current led driver
