White Plastic Enclosure Constant Voltage Dimmable LED Driver 12Vdc 50 / 60Hz

White Plastic Enclosure Constant Voltage Dimmable LED Driver 12Vdc 50 / 60Hz

    • White Plastic Enclosure Constant Voltage Dimmable LED Driver 12Vdc 50 / 60Hz
    • White Plastic Enclosure Constant Voltage Dimmable LED Driver 12Vdc 50 / 60Hz
  • White Plastic Enclosure Constant Voltage Dimmable LED Driver 12Vdc 50 / 60Hz

    Szczegóły Produktu:

    Place of Origin: China
    Nazwa handlowa: Merrytek
    Orzecznictwo: CE
    Model Number: ML40V-T

    Zapłata:

    Minimum Order Quantity: 100pcs
    Cena: Negotiation
    Packaging Details: Packed in bubble bag firstly, and then reinforced with carton for outer packing
    Delivery Time: 1, Sample and small order: Within 5 working days after receiving your payment. 2, Bulk order: 3-4 weeks after receiving deposit.
    Supply Ability: 10,000pcs per month
    Skontaktuj się teraz
    Szczegółowy opis produktu
    Product Name: 12Vdc 40W constant voltage dimmable led driver Output voltage: 12vdc
    dimming mode: Traic Output current: 3.33mA
    Input Voltage: 220-240Vac output load: 40W max
    Working Temperature: -25℃-50℃ Isolation Class: Class II, SELV
    Approvals: CE Protection Class: IP20

    Constant Voltage 12Vdc 40W Traic Dimmable LED Driver, Dimmable with RC Dimmer



    Description:

    1. Constant voltage 12Vdc

    2. Dimming RC dimmer

    3. It can match with Schneider, Simon,JUNG, DEBERKE, BUSCH, GIRA.

    5. No flickering.

    6, Leading-edge and trailing-edge dimming, compatible with RC and RL dimmer.

    7, Protection: Short circuit / Over voltage / Over temperature.

    8, Dimming range: 10%-100%



    Specifications

    Input

    Input voltage

    220-240Vac, 50/60Hz

    Power factor (PF)

    ≥0.9(@ 240Vac input, full load and without dimmer)

    Efficiency

    ≥82%(@ 240Vac input, full load and without dimmer)

    No-load power

    ≤1.5W

    Output

    Output Voltage

    12V DC

    Output Current

    3.3A max.

    Voltage accuracy

    ±5%

    Rated power

    40W Max.

    Dimming

    Dimming mode

    Trailing edge and Leading edge dimming

    Dimming range

    10%-100%

    Environment

    Working temperature

    -25℃~50℃

    Storage temperature

    -40℃~80℃

    Safety and EMC

    Insulation class

    Class II, SELV

    Withstand voltage

    Input-Output: 3.7kVac/5mA/1min

    EMC

    Compliance to EN55015, EN61000-3-2 Class C, EN61000-3-3, EN61547

    Safety

    Compliance to EN61347-1, EN61347-2-13

    Protection

    Short circuit

    Protection mode: Auto recovery

    Over temperature

    Protection mode: Auto recovery

    Others

    Dimension

    202x58x29.85mm

    Enclosure

    Plastic, white

    IP rating

    IP20

    Connection

    Input: 4-hole press-in type terminal(L, L, N, N)

    Output: Screw terminal block (LED +, LED -)

    Life time

    30,000h

    Certification

    CE
